HATEOAS

WILMA - Brand Solutions

@zmeda

Introduction

[H]ypermedia [a]s [t]he [E]ngine [o]f [A]pplication [S]tate

Standard/Specification on how servers and clients interact

Introduction

  • client interacts with server entirely through hypermedia
  • hypermedia is dynamically generated at server side
  • client needs no prior knowledge on how to interact with server
  • no contract like SOA

Motivation

Initial user feedback

  • Which are the possible state transitions (from current state)?
    • Duplicated logic on server and client side
  • How to sort, filter, paginate?
  • Where is the picture of article?

Benefits

  • Discoverability
  • Consistency
  • Ecosystem
  • Self documented API

Disadvantages

  • Complexity
  • Learning curve
  • Won't replace proper documentation

Evaluation

Known hypermedia specifications:

  • JSON API
  • Siren
  • HAL
  • Collections+JSON
  • JSON-LD

JSON API

Purpose:

  • minimize requests and data transfered
  • speed up API development
  • built by the community
  • future-proof
  • avoid bike shedding

Last update: 2015-05-29

Extendable

Example:

Get a specific order


GET /orders/1 HTTP/1.1
Accept: application/vnd.api+json



Document structure


{
  "data": null,
  "errors": null,
  "meta": null,
  "links": null,
  "included": null,
  "jsonapi": null
}



Data structure


{
  "data": {
    "id": "1",
    "type": "order",
    "links": {
      "self": "/orders/1"
    },
    "attributes": "...",
    "relationships": "..."
  }// ...
}



Data structure: Attributes


{
  "data": {
    "id": "1",
    "type": "order",
    "links": "...",
    "attributes": {
      "order-id": "1",
      "order-number": "1010101010",
      "shipment-number": "1012121212",
      "status": "approved"
    },
    "relationships": "..."
  }// ...
}



Data structure: relationships


{
  "data": {
    "id": "1",
    "type": "order",
    "links": "..."
  },
  "attributes": "...",
  "relationships": {
    "order-items": {
      "data": [
        {"id": 1, "type": "order-item"},
        {"id": 2, "type": "order-item"}
      ],
      "links": {
        "related": "/orders/1/items"
      }
    }
  }
}



Meta structure


{
  "data": {
    "id": "1",
    "type": "order",
    "links": "...",
    "attributes": "...",
    "relationships": "..."
  },
  "meta": {
    "order-items-count": 2,
    "order-lines-count": 3,
    "full-order-price": "1000"
  }
}



Siren

Siren is a hypermedia specification for representing entities.

Last update: 2015-10-21

Entity consits of:

  • class definition
  • title
  • properties
  • (sub)entities
  • links
  • actions

Example:

Get a specific order


GET /orders/1 HTTP/1.1
Response: application/vnd.siren+json



Class

Define entitiy's purpose.


{
  "class": [ "order" ],
  "title": "",
  "properties": {},
  "entities": [],
  "links": [],
  "actions": []
}



Title

Descriptive text about the entity.


{
  "class": [],
  "title": "An order entity which represents the top level order.",
  "properties": {},
  "entities": [],
  "links": [],
  "actions": []
}



Properties

A set of key-value pairs describing the state of the entity.


{
  "class": [],
  "title": "",
  "properties": {
    "order-id": "1",
    "order-number": "1010101010",
    "shipment-number": "1012121212"
  },
  "entities": [],
  "links": [],
  "actions": []
}



Entities

A collection of related sub entities. Important part is the relation between the parent and a child entity.


{
  "class": [],
  "title": "",
  "properties": {},
  "entities": [
    {
      "class": [ "items", "collection" ],
      "rel": [ "/rels/order-items" ],
      "href": "/orders/1/items"
    }
  ],
  "links": [],
  "actions": []
}



Links

Non-entity based relation bound to the entity.


{
  "class": [],
  "title": "",
  "properties": {},
  "entities": [],
  "links": [
    {
      "rel": [ "self" ],
      "href": "/orders/1/"
    }
  ],
  "actions": []
}



Actions

A collection of actions that can change the state of the entity.


{
  "class": [],
  "title": "",
  "properties": {},
  "entities": [],
  "links": [],
  "actions": [
    {
      "name": "update-order-status",
      "title": "Update an order status",
      "method": "POST",
      "href": "/orders/1",
      "type": "application/json",
      "fields": [
        { "name": "status", "type": "radio", "value": "approved" }
      ]
    }
  ]
}



HAL

Hypertext Application Language

Last update: 2013-09-18

Example:

Get a specific order


GET /orders/1 HTTP/1.1
Accept: application/hal+json



Links


{
  "_links": {
    "self": { "href": "/orders/1" }
  },
  "_embedded": {},
  "order-id": "1",
  "order-number": "1010101010",
  "shipment-number": "1012121212"
}



Resources


{
  "_links": {},
  "_embedded": {
    "items": [{
      "_links": { "self": { "href": "/orders/1/items/1"}},
      "order_item_id": "1"
    }]
  },
  "order-id": "1",
  "order-number": "1010101010",
  "shipment-number": "1012121212"
}



PAGINATION

JSON API



{
  "meta": {
    "count": 3
  },
  "data": [
    {
      "type": "order",
      "id": "1",
      "attributes": {
        "order-number": "1010121312379",
        "shipment-number": "1010123123",
        "status": "approved"
      }
    },
    {
      "type": "order",
      "id": "2",
      "attributes": {
        "order-number": "1010121312380",
        "shipment-number": "1010123124",
        "status": "approved"
      }
    },
    {
      "type": "order",
      "id": "3",
      "attributes": {
        "order-number": "1010121312381",
        "shipment-number": "1010123123",
        "status": "initial"
      }
    }
  ],
  "links": {
    "self": "/orders?page[cursor]=XYZ0",
    "first": "/orders?page[cursor]=XYZ0",
    "prev": null,
    "next": "/orders?page[cursor]=XYZ1",
    "last": "/orders?page[cursor]=XYZN"
  }
}





SIREN



{
  "class": [ "orders", "collection" ],
  "title": "A list of orders",
  "properties": {},
  "entities": [],
  "links": [
    { "rel": [ "self" ], "href": "/orders/1/" },
    { "rel": [ "first" ], "href": "/orders?page[cursor]=XYZ0" },
    { "rel": [ "next" ], "href": "/orders?page[cursor]=XYZ1" },
    { "rel": [ "last" ], "href": "/orders?page[cursor]=XYZN" },
  ],
  "actions": []
}





HAL



{
  "_links": {
    "self": { "href": "/orders/1/" },
    "first": { "href": "/orders?page[cursor]=XYZ0" },
    "next": { "href": "/orders?page[cursor]=XYZ1" },
    "last": { "href": "/orders?page[cursor]=XYZN" },
  },
  "_embedded": []
}





SORTING

Sorting is not directly a part of HATEOAS.

Best practice:


GET /orders?sort=-created_at,status HTTP/1.1



FILTERING

Filtering is not directly a part of HATEOAS.

Best practice:


GET /orders?status=initial HTTP/1.1



Conclusion

Team decision / Open discussion
